Industrial Air Coolers

DC-30 TF 1100

One way MD 1801 W

DC-30 TF 1100

Fan Type	Axial Fan 30"
Air Flow	23000 `M³` / H
Water Tank Capacity	160 L
Motor	230 V, 50 HZ, 1 PH, 0.75 HP, 3 Speed : 950 RPM
Product Dimensions	1745 mm (H) X 1100 mm (W) X 100 mm (D)
Fan Noise	< 70 db

One way MD 1801 W

Fan Type	Axial Fan 30"
Air Flow	23000 `M³` / H
Water Tank Capacity	160 L
Motor	230 V, 50 HZ, 1 PH, 0.75 HP, 3 Speed : 950 RPM
Product Dimensions	1745 mm (H) X 1100 mm (W) X 100 mm (D)
Fan Noise	< 70 db

AS 1601 W

Fan Type	Axial Fan 30"
Air Flow	18000 `M³` / H
Water Tank Capacity	160 L
Motor	230 V, 50 HZ, 1 PH, 0.5 HP, 3 Speed : 950 RPM
Product Dimensions	1745 mm (H) X 1145 mm (W) X 620 mm (D)
Cooling Pad Dimensions	1170 mm (H) X 1100 mm (W) X 100 mm (D)
Fan Noise	< 70 db

CC 1601 W Turbo 4

Fan Type	Axial Fan 30"
Air Flow	23000 `M³` / H
Water Tank Capacity	160 L
Motor	230 V, 50 HZ, 1 PH, 0.75 HP, 3 Speed : 950 RPM
Product Dimensions	1745 mm (H) X 1145 mm (W) X 620 mm (D)
Cooling Pad Dimensions	1170 mm (H) X 1100 mm (W) X 100 mm (D)
Fan Noise	< 70 db
