Document

Mini Submersible Pumps

Pump M-01

M-05 A

M-05 C

M-05 V

Pump M-10 C

Pump M-19 Concealed

Pump M-23 C

Pump M-19 Concealed

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	75 X 64 X 65
Outlet connection	1/2”Straight 'L', Type Nosal
In-put( Watt-ma @ 230V, 50Hz)	14W/95 ma
LPM @ Height	6.5 L @ 0.75m
Standard Packing	48 Pcs./Ctn

Pump M-10 C

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	90 X 56 X 75
Outlet connection	1/2”Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	15W/95 ma
LPM @ Height	8.5 L @ 1 m
Standard Packing	48 Pcs./Ctn

Pump M-01

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	96 X 95 X 89
Outlet connection	1/2”Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	15W/100 ma
LPM @ Height	9.00 L @1m
Standard Packing	36 Pcs./Ctn

Pump M-23 C

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	87 X 55 X 82
Outlet connection	1/2”ST & ½” ‘L’ Type
In-put( Watt-ma @ 230V, 50Hz)	15W/100 ma
LPM @ Height	8.5 L @1m
Standard Packing	48 Pcs./Ctn

Pump M-09 A

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	106 X 63.5 X 8 0
Outlet connection	1/2”Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	15W/100 ma
LPM @ Height	9.0 L @1m
Standard Packing	48 Pcs./Ctn

M-05 C

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	108 X 82 X 102
Outlet connection	1/2” & 3/4” Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	31W/250 ma (1/2” pipe) 35W / 265 ma (3/4" pipe)
LPM @ Height	12.5 L (1/2” pipe) @ 1m 18.5 L (3/4” pipe) @ 1m
Standard Packing	24 Pcs./Ctn

M-05 A

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	108 X 82 X 102
Outlet connection	1/2” & 3/4” Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	28W/270 ma (1/2” pipe) 33W / 282 ma (3/4" pipe)
LPM @ Height	13.5 L (1/2” pipe) @ 1m 19.5 L (3/4” pipe) @ 1m
Standard Packing	24 Pcs./Ctn

M-05 V

Operating Voltage	230V, 50 Hz
Dimensions (L X W X H,mm)	133 X 100 X 128
Outlet connection	1/2” & 3/4” Straight Nosal
In-put( Watt-ma @ 230V, 50Hz)	31W/250 ma (3/4" pipe)
LPM @ Height	13.0 L (3/4” pipe) @ 1.5 m
Standard Packing	18 Pcs./Ctn
